Ontdek de geavanceerde Pelco beveiligingscamera met een 1/2.8" CMOS-sensor en een indrukwekkende resolutie van 2592x1944 pixels. Met 5 megapixels levert deze camera haarscherpe beelden, zelfs in de meest uitdagende lichtomstandigheden, dankzij de 30m infraroodcapaciteit. Geniet van vloeiende videobeelden met een snelheid van 30 frames per seconde. Deze camera ondersteunt zowel 12V als Power over Ethernet (PoE), waardoor de installatie eenvoudig en flexibel is. Perfect voor zowel particuliere als zakelijke beveiligingstoepassingen. Verhoog uw beveiligingsniveau met de betrouwbare technologie van Pelco.
Audio
|
| Audio formats supported |
G.711/PCM |
| Sample rate |
8kHz |
| Signal-to-Noise Ratio (SNR) |
50dB |
Camera
|
| Angle of rotation |
360° |
| Camera shutter speed |
1/7,5 - 1/30000Seconde |
| Camera shutter type |
Elektronisch |
| Lens viewing angle, horizontal |
95° |
| Lens viewing angle, vertical |
69° |
| Minimum illumination |
0,02Lux |
| Number of Privacy masking areas |
64 |
| Pan range |
0 - 360° |
| Tilt angle range |
8 - 95° |
| White balance |
Auto/Handmatig |
Design
|
| Form factor |
Dome |
| Housing material |
Plastic/Polycarbonaat (PC) |
| Mounting type |
Plafond |
| Product colour |
Zwart/Wit |
Features
|
| NDAA Compliance |
Ja |
Image sensor
|
| Number of sensors |
1 |
| Optical sensor size |
1/2,8" |
| Sensor type |
CMOS |
Lens system
|
| Auto focus |
Ja |
| Focal length range |
3,4 - 10,5mm |
| Focus |
Gemotoriseerd |
| Maximum aperture number |
1,6 |
| Number of lenses |
1 |
| Zoom capability |
Ja |
Network
|
| Ethernet interface type |
Fast Ethernet |
| Ethernet LAN |
Ja |
| Networking standards |
IEEE 802.3af |
| Streaming method |
Multicast |
| Supported network protocols |
IPv6, IPv4, HTTP, HTTPS, SOAP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMPv3, ICMP, DHCP, Zeroconf, HSTS, RTP/UDP, RTP/UDP multicast, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/RTSP/HTTPS/TCP, HTTP, SRTP, SNMP v2c, SNMP v3 |
Night vision
|
| Infra-red wavelength |
850nm |
| LED type |
IR |
| Night vision distance |
30m |
Operational conditions
|
| Operating relative humidity (H-H) |
0 - 95procent |
| Operating temperature (T-T) |
-10 - 60°C |
| Storage relative humidity (H-H) |
0 - 95procent |
| Storage temperature (T-T) |
-10 - 70°C |
Package dimensions
|
| Depth (package,cm) |
2,65cm |
| Gross Weight (Package, kg) |
4,45kg |
| Height (package,cm) |
23,905cm |
| Width (package,cm) |
28,57cm |
Packaging content
|
| Number of cameras |
1 |
Performance
|
| Alarm input/output |
Ja |
| Certification |
UL/CSA/EN/IEC 62368-1, IEC 62471, FCC Part 15 Subpart B (Class B), IC ICES-003 (Class B), EN 55032 (Class B), EN 61000-6-3, EN 61000-3-2, EN 61000-3-3, EN 55035, EN 61000-6-1, EN 50130-4, EN 50121-4 |
| Connectivity technology |
Bedraad |
| Day/night mode |
Ja |
| Dynamic range |
130dB |
| Infrared (IR) cut-off filter |
Ja |
| Placement supported |
Binnen |
| Type |
IP beveiligingscamera |
| Wide Dynamic Range (WDR) |
Ja |
Ports & interfaces
|
| Ethernet LAN (RJ-45) ports |
1 |
| USB port |
Ja |
Power
|
| Battery technology |
Lithium |
| Power consumption (Power over Ethernet (PoE)) |
10Watt |
| Power source type |
Batterij/PoE |
Product dimensions
|
| Net Weight (Product, kg) |
4,45kg |
| Product Depth |
2,65cm |
| Product Height |
23,905cm |
| Product Width |
28,57cm |
Security
|
| Digest authentication |
Ja |
| HTTPS encryption |
Ja |
| Intelligent Video Surveillance (IVS) system features |
Lijnovergangsdetectie/Verlies van object/Bewegend object/Regio-ingangdetectie/Regio-uitgangdetectie |
| Password protection |
Ja |
| Privacy protection |
Ja |
| Video motion detection |
Ja |
Storage
|
| Card reader integrated |
Ja |
| Compatible memory cards |
MicroSD (TransFlash)/MicroSDHC/MicroSDXC |
| Flash memory |
512MB |
| Maximum memory card size |
1,5#ProductAttributes.Unit.Terabyte# |
| RAM capacity |
1000MB |
Sustainability
|
| Compliance certificates |
BIS/CE/cUL/KC/Norma Oficial Mexicana (NOM)/RCM/RoHS/UKCA/UL |
Vendor information
|
| Brand Name |
Pelco |
| Homepage |
https://www.pelco.com/products/cameras/fixed-ip-cameras/sarix-professional-series-4 |
| Warranty |
5#ProductAttributes.Unit.Year# |
Video
|
| Back Light Compensation (BLC) |
Ja |
| Frame rate |
60fps |
| Maximum resolution |
2592 x 1944Pixels |
| Noise reduction |
Ja |
| Noise reduction technology |
3D ruisonderdrukking |
| Supported graphics resolutions |
1280 x 720 (HD 720)/1280 x 960/1440 x 1080/1600 x 1200 (UXGA)/1920 x 1080 (HD 1080)/2560 x 1440/2592 x 1944/384 x 288/512 x 288/512 x 384/640 x 360/640 x 480 (VGA)/768 x 432/800 x 600 (SVGA) |
| Total megapixels |
5MP |
| Video formats supported |
H.264/H.265/M-JPEG |
| Video intelligence analytic |
Ja |
| Video streaming |
Ja |
