Pelco 1/2.8" CMOS, 2048x1536px, 3MP, 80m IR, 30 fps, 12V PoE
€76,27
Model: SRXP4-3V40-EBT-IR
- Detecteer objecten met Slimme Analyse
- Flexibele lensopties
- Zie in helder en weinig licht
- Gemakkelijk te implementeren
- Bescherming tegen cyberaanvallen
- Integreert met uw ONVIF-conforme VMS
De Pelco 3MP beveiligingscamera biedt een verbluffend scherpe beeldkwaliteit met zijn 1/2.8" CMOS-sensor en een resolutie van 2048x1536 pixels. Dankzij de krachtige 80 meter infrarood nachtzichtfunctie blijft uw pand zelfs 's nachts optimaal beveiligd. Met 30 frames per seconde levert deze camera soepele en gedetailleerde videobeelden. Zeer gemakkelijk te installeren met 12V Power over Ethernet (PoE), wat zowel de flexibiliteit als de efficiëntie verhoogt. Deze camera is ideaal voor zowel commerciële als residentiële toepassingen, waardoor uw beveiligingsoplossingen betrouwbaar en toekomstbestendig zijn. Zorg voor maximale veiligheid met de Pelco 3MP camera en mis nooit meer een belangrijk moment.
Audio |
|
| Audio formats supported | G.711/PCM |
| Sample rate | 8kHz |
| Signal-to-Noise Ratio (SNR) | 50dB |
Camera |
|
| Angle of rotation | 350° |
| Camera shutter speed | 1/7.5 - 1/30000Seconde |
| Camera shutter type | Elektronisch |
| Lens viewing angle, horizontal | 57° |
| Lens viewing angle, vertical | 44° |
| Minimum illumination | 0,005Lux |
| Number of Privacy masking areas | 64 |
| Pan range | -175 - 175° |
| Tilt angle range | -90 - 90° |
| White balance | Auto/Handmatig |
Design |
|
| Form factor | Bullet |
| Housing material | Aluminium |
| IK code | IK10 |
| International Protection (IP) code | IP66, IP67 |
| Mounting type | Muur |
| Product colour | Zwart/Wit |
| Protection features | Weerbestendig |
| Weatherproof | Ja |
Features |
|
| NDAA Compliance | Ja |
Image sensor |
|
| Number of sensors | 1 |
| Optical sensor size | 1/2.8" |
| Sensor type | CMOS |
Lens system |
|
| Auto focus | Ja |
| Focal length range | 4.8 - 40.8mm |
| Focus | Gemotoriseerd |
| Maximum aperture number | 1,7 |
| Number of lenses | 1 |
| Zoom capability | Ja |
Network |
|
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Ja |
| Networking standards | IEEE 802.3af |
| Streaming method | Multicast |
| Supported network protocols | IPv6, IPv4, HTTP, HTTPS, SOAP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMPv3, ICMP, DHCP, Zeroconf, HSTS, RTP/UDP, RTP/UDP multicast, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/RTSP/HTTPS/TCP, HTTP, SRTP, SNMP v2c, SNMP v3 |
Night vision |
|
| Infra-red wavelength | 850nm |
| LED type | IR |
| Night vision | Ja |
| Night vision distance | 80m |
Operational conditions |
|
| Operating relative humidity (H-H) | 0 - 95procent |
| Operating temperature (T-T) | -40 - 60°C |
| Storage relative humidity (H-H) | 0 - 95procent |
| Storage temperature (T-T) | -10 - 70°C |
Package dimensions |
|
| Depth (package,cm) | 4,2cm |
| Gross Weight (Package, kg) | 6kg |
| Height (package,cm) | 23,755000000000003cm |
| Width (package,cm) | 29,66cm |
Packaging content |
|
| Number of cameras | 1 |
Performance |
|
| Alarm input/output | Ja |
| Certification | UL/CSA/EN/IEC 62368-1, IEC 62471, FCC Part 15 Subpart B (Class B), IC ICES-003 (Class B), EN 55032 (Class B), EN 61000-6-3, EN 61000-3-2, EN 61000-3-3, EN 55035, EN 61000-6-1, EN 50130-4, EN 50121-4 |
| Connectivity technology | Bedraad |
| Day/night mode | Ja |
| Dynamic range | 130dB |
| Infrared (IR) cut-off filter | Ja |
| Placement supported | Buiten |
| Type | IP beveiligingscamera |
| Wide Dynamic Range (WDR) | Ja |
Ports & interfaces |
|
| Ethernet LAN (RJ-45) ports | 1 |
| USB port | Ja |
Power |
|
| Battery technology | Lithium |
| Power consumption (Power over Ethernet (PoE)) | 13Watt |
| Power source type | Batterij/PoE |
Product dimensions |
|
| Net Weight (Product, kg) | 6kg |
| Product Depth | 4,2cm |
| Product Height | 23,755000000000003cm |
| Product Width | 29,66cm |
Security |
|
| Digest authentication | Ja |
| HTTPS encryption | Ja |
| Intelligent Video Surveillance (IVS) system features | Lijnoverschrijding detectie/Gemiste object/Bewegend object/Region ingang detectie/Region uitgang detectie |
| Password protection | Ja |
| Privacy protection | Ja |
| Video motion detection | Ja |
Storage |
|
| Card reader integrated | Ja |
| Compatible memory cards | MicroSD (TransFlash)/MicroSDHC/MicroSDXC |
| Flash memory | 512MB |
| Maximum memory card size | 1,5#ProductAttributes.Unit.Terabyte# |
| RAM capacity | 1000MB |
Sustainability |
|
| Compliance certificates | BIS/CE/cUL/KC/Norma Oficial Mexicana (NOM)/RCM/RoHS/UKCA/UL |
Vendor information |
|
| Brand Name | Pelco |
| Homepage | https://www.pelco.com/products/cameras/fixed-ip-cameras/sarix-professional-series-4 |
| Warranty | 5#ProductAttributes.Unit.Year# |
Video |
|
| Back Light Compensation (BLC) | Ja |
| Frame rate | 30fps |
| Maximum resolution | 2048 x 1536Pixels |
| Noise reduction | Ja |
| Noise reduction technology | 3D ruisonderdrukking |
| Supported graphics resolutions | 1280 x 720 (HD 720)/1280 x 960/1600 x 1200 (UXGA)/1920 x 1080 (HD 1080)/2048 x 1152/2048 x 1536 (QXGA)/384 x 288/512 x 288/512 x 384/640 x 360/640 x 480 (VGA)/768 x 432/960 x 720 |
| Total megapixels | 3MP |
| Video formats supported | H.264/H.265/M-JPEG |
| Video intelligence analytic | Ja |
| Video streaming | Ja |
Design
| Product colour |
Black/White |
|---|---|
| Protection features |
Weatherproof |
| Form factor |
Bullet |
| Housing material |
Aluminium |
| IK code |
IK10 |
| Mounting type |
Wall |
| Weatherproof |
Yes |
Features
| NDAA Compliance |
Yes |
|---|
Lens system
| Focal length range |
4.8 – 40.8mm |
|---|---|
| Auto focus |
Yes |
| Focus |
Motorized |
| Maximum aperture number |
1,7 |
| Number of lenses |
1 |
| Zoom capability |
Yes |
Night vision
| Night vision distance |
80m |
|---|---|
| Infra-red wavelength |
850nm |
| LED type |
IR |
| Night vision |
Yes |
Logistics data
| Placement supported |
Outdoor |
|---|
Vendor information
| Brand Name |
Pelco |
|---|---|
| Homepage |
https://www.pelco.com/products/cameras/fixed-ip-cameras/sarix-professional-series-4 |
| Warranty |
5#ProductAttributes.Unit.Year# |
Video
| Total megapixels |
3MP |
|---|---|
| Back Light Compensation (BLC) |
Yes |
| Frame rate |
30fps |
| Maximum resolution |
2048 x 1536Pixels |
| Noise reduction |
Yes |
| Noise reduction technology |
3D noise reduction |
| Video formats supported |
H.264/H.265/M-JPEG |
| Video streaming |
Yes |
Audio
| Audio formats supported |
G.711/PCM |
|---|---|
| Sample rate |
8kHz |
| Signal-to-Noise Ratio (SNR) |
50dB |
Camera
| Angle of rotation |
350° |
|---|---|
| Camera shutter speed |
1/7.5 – 1/30000Second |
| Camera shutter type |
Electronic |
| Lens viewing angle, vertical |
44° |
| Minimum illumination |
0,005Lux |
| Pan range |
-175 – 175° |
| Tilt angle range |
-90 – 90° |
| White balance |
Auto/Manual |
Image sensor
| Number of sensors |
1 |
|---|---|
| Optical sensor size |
1/2.8" |
| Sensor type |
CMOS |
Network
| Ethernet interface type |
Fast Ethernet |
|---|---|
| Ethernet LAN |
Yes |
| Networking standards |
IEEE 802.3af |
| Streaming method |
Multicast |
Operational conditions
| Operating temperature (T-T) |
-40 – 60°C |
|---|---|
| Storage temperature (T-T) |
-10 – 70°C |
Package dimensions
| Depth (package,cm) |
4,2cm |
|---|---|
| Gross Weight (Package, kg) |
6kg |
| Height (package,cm) |
23,76cm |
| Width (package,cm) |
29,66cm |
Packaging content
| Number of cameras |
1 |
|---|
Performance
| Alarm input/output |
Yes |
|---|---|
| Certification |
UL/CSA/EN/IEC 62368-1, IEC 62471, FCC Part 15 Subpart B (Class B), IC ICES-003 (Class B), EN 55032 (Class B), EN 61000-6-3, EN 61000-3-2, EN 61000-3-3, EN 55035, EN 61000-6-1, EN 50130-4, EN 50121-4 |
| Connectivity technology |
Wired |
| Day/night mode |
Yes |
| Dynamic range |
130dB |
| Infrared (IR) cut-off filter |
Yes |
| Wide Dynamic Range (WDR) |
Yes |
Ports & interfaces
| USB port |
Yes |
|---|
Power
| Battery technology |
Lithium |
|---|---|
| Power source type |
Battery/PoE |
Product dimensions
| Net Weight (Product, kg) |
6kg |
|---|---|
| Product Depth |
4,2cm |
| Product Height |
23,76cm |
| Product Width |
29,66cm |
Security
| Digest authentication |
Yes |
|---|---|
| HTTPS encryption |
Yes |
| Password protection |
Yes |
| Privacy protection |
Yes |
| Video motion detection |
Yes |
Storage
| Card reader integrated |
Yes |
|---|---|
| Compatible memory cards |
MicroSD (TransFlash)/MicroSDHC/MicroSDXC |
| Maximum memory card size |
1,5#ProductAttributes.Unit.Terabyte# |
| RAM capacity |
1000MB |
Indoor unit
| Flash memory |
512MB |
|---|
Sustainability
| Compliance certificates |
BIS/CE/cUL/KC/Norma Oficial Mexicana (NOM)/RCM/RoHS/UKCA/UL |
|---|
