Pelco 1/2.8" CMOS, 2048x1536px, 3MP, 30 fps, 12V PoE
€49,34
Model: SRXP4-3V10-EMD
De Pelco 1/2.8" CMOS-camera is de ideale keuze voor superieure beveiliging en bewaking. Met een indrukwekkende resolutie van 2048x1536 pixels en 3MP biedt deze camera haarscherp beeld. Dankzij de snelle beeldsnelheid van 30 fps mis je geen enkel detail. Deze geavanceerde camera is bovendien eenvoudig te installeren met 12V PoE, wat zorgt voor een betrouwbare stroomvoorziening via Ethernet. Kies voor de Pelco CMOS-camera voor professionele beveiliging met hoogwaardige beeldkwaliteit.
Audio |
|
| Audioformaten ondersteund | G.711/PCM |
| Samplefrequentie | 8kHz |
| Signaal-ruisverhouding (SNR) | 50dB |
Camera |
|
| Rotatiehoek | 360° |
| Camera sluitertijd | 1/7.5 - 1/30000Seconde |
| Camera sluitertype | Elektronisch |
| Lens kijkhoek, horizontaal | 95° |
| Lens kijkhoek, verticaal | 69° |
| Minimale verlichting | 0,02Lux |
| Aantal Privacy maskerende gebieden | 64 |
| Pan bereik | 0 - 360° |
| Tilt hoeken bereik | 8 - 95° |
| Witbalans | Auto/Handmatig |
Ontwerp |
|
| Vormfactor | Dome |
| Behuizingsmateriaal | Plastic/Polycarbonaat (PC) |
| IK-code | IK10 |
| Internationale Bescherming (IP) code | IP66, IP67 |
| Montage type | Plafond |
| Productkleur | Zwart/Wit |
| Beschermingskenmerken | Weerbestendig |
Kenmerken |
|
| NDAA Compliance | Ja |
Beeldsensor |
|
| Aantal sensoren | 1 |
| Optische sensor grootte | 1/2.8" |
| Sensortype | CMOS |
Lenssysteem |
|
| Automatische focus | Ja |
| Brandpuntsafstand bereik | 3.4 - 10.5mm |
| Focus | Gemotoriseerd |
| Maximale diafragmawaarde | 1,6 |
| Aantal lenzen | 1 |
| Zoomcapaciteit | Ja |
Netwerk |
|
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Ja |
| Netwerkstandaarden | IEEE 802.3af |
| Streaming methode | Multicast |
| Ondersteunde netwerkprotocollen | IPv6, IPv4, HTTP, HTTPS, SOAP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMPv3, ICMP, DHCP, Zeroconf, HSTS, RTP/UDP, RTP/UDP multicast, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/RTSP/HTTPS/TCP, HTTP, SRTP, SNMP v2c, SNMP v3 |
Operationele omstandigheden |
|
| Operationele relatieve luchtvochtigheid (H-H) | 0 - 95procent |
| Operationele temperatuur (T-T) | -40 - 60°C |
| Opslag relatieve luchtvochtigheid (H-H) | 0 - 95procent |
| Opslag temperatuur (T-T) | -10 - 70°C |
Verpakkingsafmetingen |
|
| Diepte (pakket, cm) | 2,65cm |
| Brutogewicht (pakket, kg) | 4,45kg |
| Hoogte (pakket, cm) | 23,905cm |
| Breedte (pakket, cm) | 28,57cm |
Verpakkingsinhoud |
|
| Aantal camera's | 1 |
Prestaties |
|
| Alarm in-/uitgang | Ja |
| Certificering | UL/CSA/EN/IEC 62368-1, IEC 62471, FCC Part 15 Subpart B (Class B), IC ICES-003 (Class B), EN 55032 (Class B), EN 61000-6-3, EN 61000-3-2, EN 61000-3-3, EN 55035, EN 61000-6-1, EN 50130-4, EN 50121-4 |
| Connectiviteitstechnologie | Bedraad |
| Dag/nachtmodus | Ja |
| Dynamisch bereik | 130dB |
| Infrarood (IR) afsnijdfilter | Ja |
| Ondersteunde plaatsing | Buiten |
| Type | IP beveiligingscamera |
| Wide Dynamic Range (WDR) | Ja |
Poorten & interfaces |
|
| Ethernet LAN (RJ-45) poorten | 1 |
| USB-poort | Ja |
Stroom |
|
| Batterijtechnologie | Lithium |
| Stroomverbruik (Stroom via Ethernet (PoE)) | 8Watt |
| Stroombron type | Batterij/PoE |
Productafmetingen |
|
| Netto gewicht (product, kg) | 4,45kg |
| Diepte product | 2,65cm |
| Hoogte product | 23,905cm |
| Breedte product | 28,57cm |
Beveiliging |
|
| Digest-authenticatie | Ja |
| HTTPS-encryptie | Ja |
| Intelligent Video Surveillance (IVS) systeem kenmerken | Detectie van lijnoverschrijding/Gemiste objecten/Bewegend object/District ingang detectie/District uitgang detectie |
| Wachtwoordbeveiliging | Ja |
| Privacybescherming | Ja |
| Videobewegingsdetectie | Ja |
Opslag |
|
| Kaartlezer geïntegreerd | Ja |
| Compatibele geheugenkaarten | MicroSD (TransFlash)/MicroSDHC/MicroSDXC |
| Flashgeheugen | 512MB |
| Maximale geheugenkaartgrootte | 1,5#ProductAttributes.Unit.Terabyte# |
| RAM-capaciteit | 1000MB |
Duurzaamheid |
|
| Nalevingscertificaten | BIS/CE/cUL/KC/Norma Oficial Mexicana (NOM)/RCM/RoHS/UKCA/UL |
Leverancierinformatie |
|
| Merenaam | Pelco |
| Homepage | https://www.pelco.com/products/cameras/fixed-ip-cameras/sarix-professional-series-4 |
| Garantie | 5#ProductAttributes.Unit.Year# |
Video |
|
| Back Light Compensation (BLC) | Ja |
| Frame rate | 30fps |
| Maximale resolutie | 2048 x 1536Pixels |
| Ruisonderdrukking | Ja |
| Ruisonderdrukkingstechnologie | 3D ruisonderdrukking |
| Ondersteunde grafische resoluties | 1280 x 720 (HD 720)/1280 x 960/1600 x 1200 (UXGA)/1920 x 1080 (HD 1080)/2048 x 1152/2048 x 1536 (QXGA)/384 x 288/512 x 288/512 x 384/640 x 360/640 x 480 (VGA)/768 x 432/960 x 720 |
| Totaal aantal megapixels | 3MP |
| Videofor maten ondersteund | H.264/H.265/M-JPEG |
| Video intelligentie analytische | Ja |
| Video streaming | Ja |
Design
| Product colour |
Black/White |
|---|---|
| Protection features |
Weatherproof |
| Form factor |
Dome |
| Housing material |
Plastic/Polycarbonate (PC) |
| IK code |
IK10 |
| Mounting type |
Ceiling |
Features
| NDAA Compliance |
Yes |
|---|
Lens system
| Focal length range |
3.4 – 10.5mm |
|---|---|
| Auto focus |
Yes |
| Focus |
Motorized |
| Maximum aperture number |
1,6 |
| Number of lenses |
1 |
| Zoom capability |
Yes |
Logistics data
| Placement supported |
Outdoor |
|---|
Vendor information
| Brand Name |
Pelco |
|---|---|
| Homepage |
https://www.pelco.com/products/cameras/fixed-ip-cameras/sarix-professional-series-4 |
| Warranty |
5#ProductAttributes.Unit.Year# |
Video
| Total megapixels |
3MP |
|---|---|
| Back Light Compensation (BLC) |
Yes |
| Frame rate |
30fps |
| Maximum resolution |
2048 x 1536Pixels |
| Noise reduction |
Yes |
| Noise reduction technology |
3D noise reduction |
| Video formats supported |
H.264/H.265/M-JPEG |
| Video streaming |
Yes |
Audio
| Audio formats supported |
G.711/PCM |
|---|---|
| Sample rate |
8kHz |
| Signal-to-Noise Ratio (SNR) |
50dB |
Camera
| Angle of rotation |
360° |
|---|---|
| Camera shutter speed |
1/7.5 – 1/30000Second |
| Camera shutter type |
Electronic |
| Lens viewing angle, vertical |
69° |
| Minimum illumination |
0,02Lux |
| Pan range |
0 – 360° |
| Tilt angle range |
8 – 95° |
| White balance |
Auto/Manual |
Image sensor
| Number of sensors |
1 |
|---|---|
| Optical sensor size |
1/2.8" |
| Sensor type |
CMOS |
Network
| Ethernet interface type |
Fast Ethernet |
|---|---|
| Ethernet LAN |
Yes |
| Networking standards |
IEEE 802.3af |
| Streaming method |
Multicast |
Operational conditions
| Operating temperature (T-T) |
-40 – 60°C |
|---|---|
| Storage temperature (T-T) |
-10 – 70°C |
Package dimensions
| Depth (package,cm) |
2,65cm |
|---|---|
| Gross Weight (Package, kg) |
4,45kg |
| Height (package,cm) |
23,905cm |
| Width (package,cm) |
28,57cm |
Packaging content
| Number of cameras |
1 |
|---|
Performance
| Alarm input/output |
Yes |
|---|---|
| Certification |
UL/CSA/EN/IEC 62368-1, IEC 62471, FCC Part 15 Subpart B (Class B), IC ICES-003 (Class B), EN 55032 (Class B), EN 61000-6-3, EN 61000-3-2, EN 61000-3-3, EN 55035, EN 61000-6-1, EN 50130-4, EN 50121-4 |
| Connectivity technology |
Wired |
| Day/night mode |
Yes |
| Dynamic range |
130dB |
| Infrared (IR) cut-off filter |
Yes |
| Wide Dynamic Range (WDR) |
Yes |
Ports & interfaces
| USB port |
Yes |
|---|
Power
| Battery technology |
Lithium |
|---|---|
| Power source type |
Battery/PoE |
Product dimensions
| Net Weight (Product, kg) |
4,45kg |
|---|---|
| Product Depth |
2,65cm |
| Product Height |
23,905cm |
| Product Width |
28,57cm |
Security
| Digest authentication |
Yes |
|---|---|
| HTTPS encryption |
Yes |
| Password protection |
Yes |
| Privacy protection |
Yes |
| Video motion detection |
Yes |
Storage
| Card reader integrated |
Yes |
|---|---|
| Compatible memory cards |
MicroSD (TransFlash)/MicroSDHC/MicroSDXC |
| Maximum memory card size |
1,5#ProductAttributes.Unit.Terabyte# |
| RAM capacity |
1000MB |
Indoor unit
| Flash memory |
512MB |
|---|
Sustainability
| Compliance certificates |
BIS/CE/cUL/KC/Norma Oficial Mexicana (NOM)/RCM/RoHS/UKCA/UL |
|---|
