Hikvision 4 MP AcuSense Fixed Bullet Network Camera 2.8mm
€172,15
Model: DS-2CD2046G2-IU(2.8MM)(C)(BLACK)
- Hoge kwaliteit beeldvorming met 4 MP resolutie
- Uitstekende prestaties bij weinig licht met powered-by-DarkFighter technologie
- Duidelijke beeldvorming tegen sterke tegenlicht dankzij 120 dB echte WDR-technologie
- Efficiënte H.265+ compressietechnologie
- Focus op classificatie van menselijke en voertuigdoelen op basis van deep learning
- Ingebouwde microfoon voor realtime automatische beveiliging
- Water- en stofbestendig (IP67)
De Hikvision 4 MP AcuSense Fixed Bullet Netwerkcamera 2.8mm is de ultieme beveiligingsoplossing voor zowel thuis als zakelijk gebruik. Deze hoogwaardige camera biedt haarscherpe 4 MP beeldkwaliteit, zelfs onder de moeilijkste lichtomstandigheden. Dankzij de geavanceerde AcuSense-technologie worden menselijke en voertuigbewegingen nauwkeurig gedetecteerd, waardoor ongewenste alarmen worden verminderd. Met een vaste lens van 2.8mm krijgt u een breed gezichtsveld dat ideaal is voor het bewaken van grote gebieden. De robuuste bulletbehuizing is weerbestendig en bestand tegen vandalisme, wat zorgt voor betrouwbare prestaties in alle weersomstandigheden. Kies voor de Hikvision AcuSense voor geavanceerde beveiligingsfunctionaliteit en gemoedsrust.
Audio |
|
| Audioformaten ondersteund | MP3 |
| Ingebouwde microfoon | Ja |
| Monstersnelheid | 48kHz |
| Stemcodecs | AAC/G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM |
Camera |
|
| Rotatiehoek | 360° |
| Camera panoramabesturing | Ja |
| Sluitertijd camera | 1/3 - 1/100000Seconde |
| Camera tiltbesturing | Ja |
| Lens kijkhoek, diagonaal | 123° |
| Lens kijkhoek, horizontaal | 103° |
| Lens kijkhoek, verticaal | 55° |
| Pan bereik | 0 - 360° |
| Tilt hoek bereik | 0 - 90° |
| Kijkhoek, diagonaal | 123° |
| Kijkhoek, horizontaal | 103° |
| Kijkhoek, verticaal | 55° |
Design |
|
| Behuizing materiaal | Aluminium |
| Internationale Bescherming (IP) code | IP67 |
| Montage type | Plafond/muur |
| Productkleur | Zwart |
| Beschermingsfuncties | Stofbestendig/Waterbestendig |
Beeldsensor |
|
| Aantal sensoren | 1 |
| Optische sensor grootte | 1/3" |
| Progressieve scan | Ja |
| Sensortype | CMOS |
Lenssysteem |
|
| Detectieafstand (wijd) | 60m |
| Vaste brandpuntsafstand | 2,8mm |
| Brandpuntsafstand bereik | 2,8cm |
| Identificatieafstand (wijd) | 6m |
| Maximale diafragma nummer | 1,4 |
| Aantal lenzen | 1 |
| Observeerafstand (wijd) | 23,8m |
| Herkenningsafstand (wijd) | 12m |
Beheerfuncties |
|
| Gedragsanalyse | Inbraakalarm/ lijnoverschrijdingsdetectie/ regio-ingangdetectie/ regio-uitgangdetectie |
| Resetknop | Ja |
| Webgebaseerd beheer | Ja |
Netwerk |
|
| Bluetooth | Nee |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Ja |
| Netwerkstandaarden | IEEE 802.1x/IEEE 802.3af |
| Aantal gebruikers | 32gebruiker(s) |
| Kwaliteit van Dienst (QoS) ondersteuning | Ja |
| Ondersteunde netwerkprotocollen | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP |
| Wi-Fi | Nee |
Nachtzicht |
|
| Infraroodgolflengte | 850nm |
| LED type | IR |
| Nachtzicht | Ja |
| Nachtzicht afstand | 40m |
Operationele omstandigheden |
|
| Operationele relatieve vochtigheid (H-H) | 0 - 95procent |
| Operationele temperatuur (T-T) | -30 - 60°C |
| Opslag relatieve vochtigheid (H-H) | 0 - 95procent |
| Opslag temperatuur (T-T) | -30 - 60°C |
Verpakkingsafmetingen |
|
| Diepte (pakket,cm) | 21,6cm |
| Brutogewicht (pakket, kg) | 0,75kg |
| Hoogte (pakket,cm) | 11,8cm |
| Breedte (pakket,cm) | 12,1cm |
Verpakkingsinhoud |
|
| Aantal camera's | 1 |
Prestatie |
|
| Connectiviteitstechnologie | Bekabeld |
| Dag/nachtmodus | Ja |
| Infrarood (IR) afkapfilter | Ja |
| Taalondersteuning | Bulgaars/TSjechisch/Deens/Nederlands/Engels/Estisch/Fins/Frans/Duits/Grieks/Hongaars/Italiaans/Japans/Koreaans/LAT/Litouws/Noors/Pols/Portugees/Roemeens/Russisch/SER/Slowaaks/Sloveens/Spaans/Zweeds/Thais/Traditioneel Chinees/Turks/Oekraïens/Vietnamese |
| Aantal talen | 33 |
| Plaatsing ondersteund | Buiten |
| Wide Dynamic Range (WDR) | Ja |
Poorten & interfaces |
|
| Ethernet LAN (RJ-45) poorten | 1 |
Voeding |
|
| DC output stroom | 0,5A |
| DC output spanning | 12 |
| Stroomverbruik (max) | 6Watt |
| Stroomverbruik (Voeding via Ethernet (PoE)) | 7Watt |
| Type voedingsbron | DC/PoE |
Productafmetingen |
|
| Nettogewicht (Product, kg) | 0,45kg |
| Productdiepte | 21,6cm |
| Producthoogte | 11,8cm |
| Productbreedte | 12,1cm |
Beveiliging |
|
| Anti-flikker | Ja |
| Hartslag | Ja |
| HTTPS-encryptie | Ja |
| Intelligent Video Bewakings (IVS) systeemfuncties | Scèneverandering |
| IP-adresfiltering | Ja |
| Spiegel | Ja |
| Wachtwoordbeveiliging | Ja |
| Videobewegingdetectie | Ja |
Opslag |
|
| Ingebouwde HDD | Nee |
| Geïntegreerde kaarlezer | Ja |
| Compatibele geheugenkaarten | MicroSD (TransFlash)/MicroSDHC/MicroSDXC |
| Maximale geheugenkaartgrootte | 256GB |
Technische details |
|
| Duurzaamheidscertificaten | CE/REACH |
Leverancier informatie |
|
| Merknaam | Hikvision |
| Garantie | 3#ProductAttributes.Unit.Year# |
Video |
|
| Back Light Compensation (BLC) | Ja |
| Bitrate | 32 Kbps - 8 Mbps |
| Bitratecontrole | Constante Bit Rate (CBR)/Variabele Bit Rate (VBR) |
| Frame rate | 30fps |
| Highlight Compensation (HLC) | Ja |
| Afbeeldingskwaliteit aanpassing | Helderheid/Contrast/Verzadiging/Structuur |
| Maximale resolutie | 2688 x 1520Pixels |
| Ruisonderdrukking | Ja |
| Ruisonderdrukkingstechnologie | 3D ruisonderdrukking |
| Privacy masking | Ja |
| Region of Interest (ROI) codering | Ja |
| Ondersteunde graphics resoluties | 1280 x 720 (HD 720)/1920 x 1080 (HD 1080)/2688 x 1520/640 x 360/640 x 480 (VGA) |
| Totaal aantal megapixels | 4MP |
| Videocompressieformaten | H.264/H.264+/H.265/H.265+/M-JPEG |
| Videostreaming | Ja |
Gewicht & afmetingen |
|
| Diameter | 7cm |
| Lengte | 16,17cm |
Design
| Product colour |
Black |
|---|---|
| Protection features |
Dust resistant/Water resistant |
| Housing material |
Aluminium |
| Mounting type |
Ceiling/wall |
Lens system
| Focal length range |
2,8cm |
|---|---|
| Detect distance (wide) |
60m |
| Fixed focal length |
2,8mm |
| Identify distance (wide) |
6m |
| Maximum aperture number |
1,4 |
| Number of lenses |
1 |
| Observe distance (wide) |
23,8m |
| Recognize distance (wide) |
12m |
Night vision
| Night vision distance |
40m |
|---|---|
| Infra-red wavelength |
850nm |
| LED type |
IR |
| Night vision |
Yes |
Logistics data
| Placement supported |
Outdoor |
|---|
Vendor information
| Brand Name |
Hikvision |
|---|---|
| Warranty |
3#ProductAttributes.Unit.Year# |
Video
| Total megapixels |
4MP |
|---|---|
| Back Light Compensation (BLC) |
Yes |
| Bit rate |
32 Kbps – 8 Mbps |
| Bit rate control |
Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Frame rate |
30fps |
| Highlight Compensation (HLC) |
Yes |
| Image quality adjustment |
Brightness/Contrast/Saturation/Sharpness |
| Maximum resolution |
2688 x 1520Pixels |
| Noise reduction |
Yes |
| Noise reduction technology |
3D noise reduction |
| Privacy masking |
Yes |
| Video compression formats |
H.264/H.264+/H.265/H.265+/M-JPEG |
| Video streaming |
Yes |
Audio
| Audio formats supported |
MP3 |
|---|---|
| Sample rate |
48kHz |
| Voice codecs |
AAC/G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM |
Features
| Built-in microphone |
Yes |
|---|
Camera
| Angle of rotation |
360° |
|---|---|
| Camera pan control |
Yes |
| Camera shutter speed |
1/3 – 1/100000Second |
| Camera tilt control |
Yes |
| Lens viewing angle, diagonal |
123° |
| Lens viewing angle, vertical |
55° |
| Pan range |
0 – 360° |
| Tilt angle range |
0 – 90° |
| Viewing angle, diagonal |
123° |
| Viewing angle, horizontal |
103° |
| Viewing angle, vertical |
55° |
Image sensor
| Number of sensors |
1 |
|---|---|
| Optical sensor size |
1/3" |
| Progressive scan |
Yes |
| Sensor type |
CMOS |
Management features
| Behavior analysis |
Intrusion detection/Line crossing detection/Region entrance detection/Region exiting detection |
|---|---|
| Reset button |
Yes |
| Web-based management |
Yes |
Network
| Bluetooth |
No |
|---|---|
| Ethernet interface type |
Fast Ethernet |
| Ethernet LAN |
Yes |
| Networking standards |
IEEE 802.1x/IEEE 802.3af |
| Number of users |
32gebruiker(s) |
| Supported network protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP |
| Wi-Fi |
No |
Operational conditions
| Operating temperature (T-T) |
-30 – 60°C |
|---|---|
| Storage temperature (T-T) |
-30 – 60°C |
Package dimensions
| Depth (package,cm) |
21,6cm |
|---|---|
| Gross Weight (Package, kg) |
0,75kg |
| Height (package,cm) |
11,8cm |
| Width (package,cm) |
12,1cm |
Packaging content
| Number of cameras |
1 |
|---|
Performance
| Connectivity technology |
Wired |
|---|---|
| Day/night mode |
Yes |
| Infrared (IR) cut-off filter |
Yes |
| Number of languages |
33 |
| Wide Dynamic Range (WDR) |
Yes |
Power
| DC output current |
0,5A |
|---|---|
| DC output voltage |
12 |
| Power consumption (max) |
6Watt |
| Power source type |
DC/PoE |
Product dimensions
| Net Weight (Product, kg) |
0,45kg |
|---|---|
| Product Depth |
21,6cm |
| Product Height |
11,8cm |
| Product Width |
12,1cm |
Security
| Anti-flicker |
Yes |
|---|---|
| Heartbeat |
Yes |
| HTTPS encryption |
Yes |
| IP address filtering |
Yes |
| Mirror |
Yes |
| Password protection |
Yes |
| Video motion detection |
Yes |
Storage
| Built-in HDD |
No |
|---|---|
| Card reader integrated |
Yes |
| Compatible memory cards |
MicroSD (TransFlash)/MicroSDHC/MicroSDXC |
| Maximum memory card size |
256GB |
Technical details
| Sustainability certificates |
CE/REACH |
|---|
Weight & dimensions
| Diameter |
7cm |
|---|---|
| Length |
16,17cm |
